Order Code ALS_XE/E-OW(L)-S-F-6 White LED
LED fittings provide long life and low maintenance operation, low power consumption and reduced running costs compared to Halogen (a saving of typically 80%). Also available as Blue Taxiway Edge light or a Red Unserviceability Stop Bar Light
Features
- Adaptable to all kind of CCR’s and ILCMS systems.
- Specially designed compact structure for LED light source.
- Two tier optical lens providing excellent consistency
- Modulised electrical driver and LED assembly for simplicity of maintenance.
- Efficient and stable optical output, suitable for operation with 6.6A and 2.2A CCR’s.
- Unique optical design, ensuring luminous efficacy and colour consistency.
- Advanced thermal management solution to extend life expectancy to 80,000 hours.
- Innovative design means the electronics are protected against shock and vibration.
- Precision aluminium components, treated with a special external coating.
- Built in surge protection.
- Fail safe system for protection on the airfield.
- Optional electronic built-in by-pass device to short-circuit a defective light.
Power Consumption
White LED 5VA
Components
Standards
ICAO ・ Annex 14 Volume I
EASA ・ CS-ADR-DSN
IEC ・ TS 61827
AENA ・ DIN/DSEYN/PPT/017
This ALS LED Airfield Light is designed to meet the photometric, electrical, and environmental requirements of ICAO Annex 14 Volume I, EASA CS-ADR-DSN, and FAA AC 150/5345-46 (EB No. 67
Compliant with NATO, UK and US Military standards.
Dimensions
Dimensions 2 Pack 300mm (L) x 243mm (W) x 115mm (H)
Net Weight 1.2Kg
Gross Weight 2.6Kg
